Norsat 9000XCN-2 – Ka-Band Single-Band External Reference PLL LNB, N-Type (50Ω)
$1,179.00
• Input Band: 20.20–21.20 GHz
• LO Reference: External 10 MHz
• Noise Figure: 1.5 dB
• Output Connector: N-type, 50 Ω
• Integrated Waveguide Isolator: No
Security policy
Delivery policy
Return policy
Norsat 9000XCN-2 Single-Band Ka-Band External Reference LNB
The Norsat 9000XCN-2 is a single-band Ka-Band PLL LNB requiring a 10 MHz external reference, designed for precision satellite reception in the 20.20–21.20 GHz band. With a typ. 1.5 dB noise figure and rugged IP67-rated housing, it ensures stable, low-noise performance for demanding SATCOM applications.
Frequency Band: 20.20–21.20 GHz
Output Frequency: 950–1950 MHz
Local Oscillator: 19.25 GHz
LO Stability: External 10 MHz reference (-5 to +5 dBm)
Noise Figure: typ. 1.5 dB, max. 1.6 dB
Gain: typ. 60 dB (55–65 dB range), ≤4 dB p-p flatness
Image Rejection: 40 dBc min
Output Connector: N-Type, 50 Ohm
Input: WR-42 waveguide grooved
Power: +12 to +24 VDC, 350 mA max
Environmental: -40°C to +60°C, IP67
Dimensions: 98.7 x 42.4 x 42.2 mm; Weight: 0.27 kg
Made in Republic of Korea; ECCN: EAR99
9000XCN-2
- Frequency Band
- Ka-Band
- Frequency Range
- 20.20 – 21.20 GHz
- Number of Bands
- Single-Band
- Output Band
- Band 1: 950 – 1950 MHz
- LO Frequency
- 19.25 GHz
- LO Stability
- External Reference
- Noise Figure
- 1.5 dB
- Typical Gain
- 60 dB
- Input Interface
- WR-42 Waveguide Grooved
- Output Connector
- N Type 50 Ohm
