Norsat 9000XIS – Ka-Band Single-Band External Reference PLL LNB, SMA-Type
$5,500.00
• Input Band: 20.20–21.20 GHz
• LO Reference: External 10 MHz
• Noise Figure: 1.5 dB
• Output Connector: SMA-type
Security policy
Delivery policy
Return policy
Norsat 9000XIS Single-Band Ka-Band External Reference LNB
The Norsat 9000XIS is a single-band Ka-Band PLL LNB requiring a 10 MHz external reference, designed for stable downlinking across 20.20–21.20 GHz. With a typ. 1.5 dB noise figure and rugged IP67-rated housing, it delivers precise frequency stability and reliable SATCOM performance.
Frequency Band: 20.20–21.20 GHz
Output Frequency: 1000–2000 MHz
Local Oscillator: 19.20 GHz
LO Stability: External 10 MHz reference (-5 to +5 dBm)
Noise Figure: typ. 1.5 dB, max. 1.8 dB
Gain: typ. 60 dB (56–64 dB range), ≤4 dB p-p flatness
Image Rejection: 40 dBc min
Output Connector: SMA-Type, 50 Ohm
Input: WR-42 waveguide grooved
Power: +15 to +24 VDC, 400 mA max
Environmental: -40°C to +60°C, IP67
Dimensions: 153 x 77 x 51 mm; Weight: 0.7 kg
Made in Japan; ECCN: EAR99
9000XIS
- Frequency Band
- Ka-Band
- Frequency Range
- 20.20 – 21.20 GHz
- Number of Bands
- Single-Band
- Output Band
- 1000-2000 MHz
- LO Frequency
- 19.20 GHz
- LO Stability
- External Reference
- Noise Figure
- 1.5 dB
- Typical Gain
- 60 dB
- Input Interface
- WR-42 Waveguide Grooved
- Output Connector
- SMA Type 50 Ohm
