Norsat 9000XT-3N – Ka-Band Triple-Band PLL LNB, N-Type (50Ω)
$4,435.00
Covers 17.30–20.20 GHz input range
Supports 3 sub-bands:
• Band 1: 17.30–18.30 GHz
• Band 2: 18.30–19.30 GHz
• Band 3: 19.30–20.20 GHz
• LO Reference: External 10 MHz
• Output Connector: N-type, 50 Ω
Security policy
Delivery policy
Return policy
Norsat 9000XT-3N Triple-Band Ka-Band External Reference LNB
The Norsat 9000XT-3N is a triple-band Ka-Band PLL LNB requiring a 10 MHz external reference, engineered for precision SATCOM reception across 17.30–20.20 GHz. With typ. 1.6 dB noise figure, stable gain, and rugged IP67-rated housing, it provides reliable performance for demanding satellite applications.
Frequency Band 1: 17.30–18.30 GHz
Frequency Band 2: 18.30–19.30 GHz
Frequency Band 3: 19.30–20.20 GHz
Output Frequencies: 950–1950 MHz (all bands)
Local Oscillators: 16.35 / 17.35 / 18.35 GHz
LO Stability: External 10 MHz reference (-5 to +5 dBm)
Noise Figure: typ. 1.6 dB, max. 2.0 dB
Gain: typ. 65 dB (58–70 dB range), ≤4 dB p-p flatness
Control: 13V (Band 1), 18V (Band 2), 13V + 22 kHz (Band 3)
Image Rejection: 40 dBc min @ 16.35 GHz, 30 dBc min @ 17.35 GHz
Output Connector: N-Type, 50 Ohm
Input: WR-42 waveguide grooved
Power: +11 to +26 VDC, 400 mA max
Environmental: -40°C to +60°C, IP67
Dimensions: 133 x 70 x 39 mm; Weight: 0.5 kg
Made in Canada; ECCN: EAR99
9000XT-3N
- Frequency Band
- Ka-Band
- Frequency Range
- 17.30 – 20.20 GHz
- Number of Bands
- 3-Band
- Sub-Band
- Band 1: 17.30 – 18.30 GHz
- Sub-Band
- Band 2: 18.30 – 19.30 GHz
- Sub-Band
- Band 3: 19.30 – 20.20 GHz
- Output Band
- Band 1: 950 – 1950 MHz
- Output Band
- Band 2: 950 – 1950 MHz
- Output Band
- Band 3: 950 – 1950 MHz
- LO Frequency
- Multiple LO
- LO Stability
- External Reference
- Noise Figure
- 1.6 dB
- Typical Gain
- 65 dB
- Input Interface
- WR-42 Waveguide Grooved
- Output Connector
- N Type 50 Ohm
