Norsat 9000LBN – Ka-Band Single-Band DRO LNB, N-Type (50Ω)

Norsat 9000LBN Single-Band Ka-Band DRO LNB

The Norsat 9000LBN is a single-band Ka-Band DRO LNB with ±2 MHz LO stability and a typ. 1.2 dB noise figure, designed for reliable SATCOM reception across 19.20–20.20 GHz. It features a 50 Ohm N-type output, WR-42 waveguide input, and IP67-rated housing for rugged field operation.

Frequency Band: 19.20–20.20 GHz

Output Frequency: 950–1950 MHz
Local Oscillator: 18.25 GHz
LO Stability: ±2 MHz (DRO)
Noise Figure: typ. 1.2 dB, max. 1.5 dB
Gain: typ. 60 dB (55–65 dB range), ≤5 dB p-p flatness
Input VSWR: 2.5:1 max
Output P1dB: +3 dBm min
Output VSWR: 2.5:1 max
Phase Noise: -95 dBc/Hz @100 kHz
Output Connector: N-Type, 50 Ohm
Input: WR-42 waveguide grooved
Power: +12 to +24 VDC, 200 mA max
Environmental: -30°C to +60°C operation, -40°C to +80°C storage, IP67
Dimensions: 111 x 42 x 42 mm; Weight: 0.3 kg
Made in Republic of Korea; ECCN: EAR99
