Actox AL3448(X)/N Full C-Band PLL LNB
• Input Band: 3.4–4.8 GHz
• LO Stability: ±5, ±10, ±25 kHz or External Reference
• Noise Temperature: 30K
• Output Connector: F or N Type
Security policy
Delivery policy
Return policy
Actox AL3448(X)/N Full C-Band LNB
The Actox AL3448(X)/N is a single-band C-Band PLL LNB with ±5, ±10, ±25 kHz or external reference LO stability and a typ. 30K noise temperature, designed for precise downlinking from 3.4 to 4.8 GHz. Featuring a 75 Ohm F-type output or a 50 Ohm N-type output, CPR229G waveguide input, and rugged IP-rated construction, it ensures stable, high-quality SATCOM reception.
Frequency Band: 3.4–4.8 GHz
Output Frequency: 950–2350 MHz
Local Oscillator: 5.75 GHz
LO Stability: ±5, ±10, ±25 kHz or External Reference
Noise Temperature: 30K
Conversion Gain: 65 dB typ. ≤6 dB p-p flatness
Output Connector: F 75 Ohm or N 50 Ohm
Input: CPR229G waveguide grooved
Power: +12 to +24 VDC, 250 mA max
Environmental: -40°C to +60°C
Dimensions: 164.5 x 98.8 x 70 mm; Weight: 0.575 kg
AL3448(X)/N
- Type
- Single LNBs
- Frequency Band
- C-Band
- Frequency Range
- 3.4 – 4.8 GHz
- Number of Bands
- Single-Band
- Output Band
- Band 1: 950 – 2350 MHz
- LO Frequency
- 5.75 GHz
- LO Stability
- ±5 kHz
- LO Stability
- ±10 kHz
- LO Stability
- ±25 kHz
- LO Stability
- External Reference
- Noise Figure
- 0.43 dB
- Typical Gain
- 65 dB
- Input Interface
- CPR 229G Waveguide Grooved
- Output Connector
- F Type 75 Ohm
- Output Connector
- N Type 50 Ohm
