Actox ALG3742010/N C-Band 5G Rejection LNB
• Input Band: 3.7–4.2 GHz
• Rejection Range: <3.525 & >4.80 GHz
• LO Stability: ±10 kHz
• Noise Temperature: 30K
• Output Connector: F or N Type
Security policy
Delivery policy
Return policy
Actox ALG3742010 C-Band 5G Rejection LNB
The Actox ALG3742010 is a single-band C-Band 5G rejection LNB with ±10 kHz LO stability and a typ. 30K noise temperature, designed for removing 5G interference of Rejection Range: <3.525 & >4.80 GHz.
Frequency Band: 3.7–4.2 GHz
Output Frequency: 950–1450 MHz
Local Oscillator: 5.15 GHz
LO Stability: ±10 kHz
Noise Temperature: 30K
Conversion Gain: 60 dB typ. ≤4 dB p-p flatness
Output Connector: F 75 Ohm or N 50 Ohm
Input: CPR229G waveguide grooved
Power: +12 to +24 VDC, 250 mA max
Environmental: -40°C to +60°C
Dimensions: 164.5 x 98.8 x 70 mm; Weight: 0.575 kg
ALG3742010, ALG374010N
- Type
- Single LNBs
- Frequency Band
- C-Band
- Frequency Range
- 3.7 – 4.2 GHz
- Number of Bands
- Single-Band
- Output Band
- Band 1: 950 – 1450 MHz
- LO Frequency
- 5.15 GHz
- LO Stability
- ±10 kHz
- Noise Figure
- 0.43 dB
- Typical Gain
- 60 dB
- Input Interface
- CPR 229G Waveguide Grooved
- Output Connector
- F Type 75 Ohm
- Output Connector
- N Type 50 Ohm
Specific References
• Input Band: 3.7–4.2 GHz
• Rejection Range: <3.525 & >4.80 GHz
• LO Stability: ±10 kHz
• Noise Temperature: 30K
• Output Connector: F or N Type
