Actox AL11300010 Ku-Band PLL LNB
The Actox AL11300010 / AL11300010N is a Ku-Band PLL LNB with ±10 kHz LO stability and a max. 0.8 dB noise figure, designed for precise downlinking from 12.25 to 12.75 GHz.
Frequency Band: 12.25–12.75 GHz
Output Frequency: 950–1450 MHz
Local Oscillator: 11.3 GHz
Noise Figure: 0.8 dB max.
Conversion Gain: 60 dB typ.
Output Connector: F 75 Ohm or N 50 Ohm
Input: WR75 waveguide grooved
Power: +12 to +24 VDC, 350 mA max
Environmental: -40°C to +60°C
Dimensions: 98.5 x 42 x 42 mm; Weight: 0.3 kg
AL11300010, AL11300010N
- Type
- Single LNBs
- Frequency Band
- Ku-Band
- Frequency Range
- 12.25 – 12.75 GHz
- Number of Bands
- Single-Band
- Output Band
- Band 1: 950 – 1450 MHz
- LO Frequency
- 11.30 GHz
- LO Stability
- ±10 kHz
- Noise Figure
- 0.8 dB
- Typical Gain
- 60 dB
- Input Interface
- WR-75 waveguide grooved
- Output Connector
- F Type 75 Ohm
- Output Connector
- N Type 50 Ohm
