Actox AL100X / AL100XN External Reference Ku-Band PLL LNB
• Input Band: 10.95–11.7 GHz
• LO Stability: External Reference
• Noise Figure: 0.8 dB
• Output Connector: F or N Type
Security policy
Delivery policy
Return policy
Actox AL100X Ku-Band PLL LNB
The Actox AL100X / AL100XN is a Ku-Band PLL LNB with external reference LO stability and a max. 0.8 dB noise figure, designed for precise downlinking from 10.95 to 11.7 GHz.
Frequency Band: 10.95–11.7 GHz
Output Frequency: 950–1700 MHz
Local Oscillator: 10.0 GHz
Noise Figure: 0.8 dB max.
Conversion Gain: 60 dB typ.
Output Connector: F 75 Ohm or N 50 Ohm
Input: WR75 waveguide grooved
Power: +12 to +24 VDC, 350 mA max
Environmental: -40°C to +60°C
Dimensions: 99.5 x 42 x 42 mm; Weight: 0.3 kg
AL100X, AL100XN
- Type
- Single LNBs
- Frequency Band
- Ku-Band
- Frequency Range
- 10.95 – 11.70 GHz
- Number of Bands
- Single-Band
- Output Band
- Band 1: 950 – 1700 MHz
- LO Frequency
- 10.00 GHz
- LO Stability
- External Reference
- Noise Figure
- 0.8 dB
- Typical Gain
- 60 dB
- Input Interface
- WR-75 waveguide grooved
- Output Connector
- F Type 75 Ohm
- Output Connector
- N Type 50 Ohm
Specific References
• Input Band: 10.95–11.7 GHz
• LO Stability: External Reference
• Noise Figure: 0.8 dB
• Output Connector: F or N Type
