iDirect OM6000 Satellite Modulator Board

iDirect OM6000 OEM Satellite Modulator Board

The iDirect OM6000 OEM Satellite Modulator Board is a high-performance DVB-S2X compliant modulator designed for broadcast, contribution, and distribution applications.

Supporting advanced modulation schemes up to 64APSK and offering a software upgrade path to DVB-S2X, the OM6000 provides flexibility and long-term scalability for OEM integrators and satellite system manufacturers.

Key Features

DVB-S2X compliant with S2 Extensions support

ModCods up to 64APSK

Symbol rates from 0.05 to 72 Msps

Selectable IF or L-band output (software controlled)

Clean Channel Technology® compliant

RF Carrier ID support (DVB-CID)

Backward compatible with legacy modulator boards

JSON-RPC and RMCP management interfaces

Key Specifications

Frequency Range:

L-band: 950 – 2150 MHz

IF-band: 50 – 90 / 100 – 180 MHz

Symbol Rate: 0.05 – 72 Msps

Modulation: QPSK, 8PSK, 16APSK, 32APSK, 64APSK

Standards: DVB-S, DVB-DSNG, DVB-S2, DVB-S2X

Output Level: -35 to +5 dBm

Power Consumption: < 15W

Applications

Broadcast and video distribution (UHD/HD/SD)

Satellite contribution and DSNG

Teleport and gateway infrastructure

OEM encoder/modulator integration

Satellite service providers
