iDirect M6100 Broadcast Satellite Modulator

iDirect M6100 Broadcast Satellite Modulator

The iDirect M6100 is a high-performance DVB-S2X broadcast satellite modulator designed for DTH, DSNG, and contribution networks, delivering exceptional bandwidth efficiency, reliability, and advanced modulation capabilities for professional satellite uplinks.

Key Features

DVB-S2X / DVB-S2 / DVB-S / DSNG compliant

Symbol rate up to 72 Msps, data rates up to 216 Mbps

Supports up to 256APSK modulation

IF and L-band output (950–2150 MHz)

Optional integrated Ku-band or C-band upconverter

Input redundancy (ASI / IP) with fast switching

Clean Channel Technology® (up to 15% efficiency gain)

Equalink® 3 predistortion (up to 10% bandwidth gain)

Applications

Broadcast DTH uplinks

DSNG (Digital Satellite News Gathering)

TV & radio contribution networks

VSAT hubs and teleport systems

Telco and trunking infrastructure

Key Specifications

Symbol Rate: 50 ksps – 72 Msps

Output: IF (50–180 MHz) or L-band (950–2150 MHz)

Interfaces: ASI, GbE (IP over UDP/RTP)

Modulation: QPSK to 256APSK

BUC Power: Optional 24V / 48V

Redundancy: 1+1 and N+1 support

Form Factor: 1RU rackmount
