Norsat ULC-0-75-LLC

$1,600.00

Universal LNB Controller

Reference: No reference

Connector: F Type 75 Ohm

Control Interface: Line Length Compensation with Switch

Quantity

Last items in stock

Security policy

Delivery policy

Return policy

Norsat ULC-0-75-LLC Universal LNB Controller with Line Length Compensation

The Norsat ULC-0-75-LLC is a 75 Ohm LNB controller with F-type connectors and a line length compensation (LLC) interface. It provides 13V/18V output and tone generation for reliable control of LNBs in long-cable RF environments, housed in a rugged IP66-rated enclosure.

Output Voltages: 12.5 – 13.5 VDC / 17.3 – 18.7 VDC
Tone Frequency: 20 – 24 kHz
Tone Amplitude: 0.55 – 0.9 Vpp
Reference Signal: None
Control Interface: Switch, cable, and LLC with logic levels
Logic Levels: Low: 0–0.8 V, High: 2.5–7 V
Connector Type: 75 Ohm F-Connector
Output VSWR: max. 2.0:1
Output Current: max. 500 mA
Power Supply: +23 to +25 VDC
Current Consumption: 450 mA @ 24 VDC
IP Rating: IP66
Operating Temp: –30°C to +60°C
Dimensions: 130 × 95 × 30 mm
Weight: 0.66 kg
