Norsat ULC-1-75-LLC

$2,100.00

Universal LNB Controller

Reference: 10 MHz Reference

Connector: F Type 75 Ohm

Control Interface: Line Length Compensation with Switch

Quantity

Lead Time: 2 - 3 Weeks

Security policy

Delivery policy

Return policy

Norsat ULC-1-75-LLC Universal LNB Controller with Ref & LLC

The Norsat ULC-1-75-LLC is a 75 Ohm LNB controller with F-type connectors, internal 10 MHz reference, and line length compensation. It supports 13V/18V output and tone signal for powering LNBs in long-cable satellite deployments—rugged and IP66-rated.

Reference Signal: Internal 10 MHz
Output Voltages: 12.5 – 13.5 VDC / 17.3 – 18.7 VDC
Tone Frequency: 20 – 24 kHz
Tone Amplitude: 0.55 – 0.9 Vpp
Control Interface: Switch, cable, LLC (L: 0–0.8 V, H: 2.5–7 V)
Connector Type: 75 Ohm F-Connector
Output VSWR: max. 2.0:1
Output Current: max. 500 mA
Power Supply: +23 to +25 VDC
Current Consumption: 600 mA @ 24 VDC
IP Rating: IP66
Operating Temp: –30°C to +60°C
Dimensions: 130 × 95 × 30 mm
Weight: 0.66 kg
