Norsat ULC-1-50S-LLC

$2,300.00

Universal LNB Controller

Reference: 10 MHz Reference

Connector: SMA Type 50 Ohm

Control Interface: Line Length Compensation with Switch

Quantity

Lead Time: 2 - 3 Weeks

Security policy

Delivery policy

Return policy

Norsat ULC-1-50s-LLC Universal LNB Controller with Ref & LLC

The Norsat ULC-1-50s-LLC is a 50 Ohm SMA LNB controller with internal 10 MHz reference and line length compensation interface. It delivers 13V/18V output and tone signal, with switch and logic-level control, in a rugged IP66 housing for long-cable SATCOM applications.

Reference Signal: Internal 10 MHz

Output Voltages: 12.5 – 13.5 VDC / 17.3 – 18.7 VDC
Tone Frequency: 20 – 24 kHz
Tone Amplitude: 0.55 – 0.9 Vpp
Control Interface: Switch, cable, LLC (L: 0–0.8 V, H: 2.5–7 V)
Connector Type: 50 Ohm SMA Connector
Output VSWR: max. 2.0:1
Output Current: max. 500 mA
Power Supply: +23 to +25 VDC
Current Consumption: 600 mA @ 24 VDC
IP Rating: IP66
Operating Temp: –30°C to +60°C
Dimensions: 130 × 95 × 30 mm
Weight: 0.66 kg
