Norsat ULC-2N-50-CI

$2,000.00

Universal LNB Controller

Reference: 10 MHz Injection Port (N Connector)

Connector: N Type 50 Ohm

Control Interface: Control Interface Cable

Quantity
Last items in stock



Security policy



Delivery policy



Return policy

Norsat ULC-2N-50-CI Universal LNB Controller with Ref & CI

The Norsat ULC-2N-50-CI is a 50 Ohm N-type LNB controller featuring a 10 MHz reference injection port and control interface cable. It supports 13V/18V output and tone signal with switch or logic-level control. Rugged IP66-rated design built for reliable SATCOM applications.

Reference Signal: 10 MHz injection port (N-Connector)
Output Voltages: 12.5 – 13.5 VDC / 17.3 – 18.7 VDC
Tone Frequency: 20 – 24 kHz
Tone Amplitude: 0.55 – 0.9 Vpp
Control Interface: Switch, cable, LLC (L: 0–0.8 V, H: 2.5–7 V)
Connector Type: 50 Ohm N-Connector
Output VSWR: max. 2.0:1
Output Current: max. 500 mA
Power Supply: +23 to +25 VDC
Current Consumption: 600 mA @ 24 VDC
IP Rating: IP66
Operating Temp: –30°C to +60°C
Dimensions: 130 × 95 × 30 mm
Weight: 0.66 kg
Made in Canada

ULC-2N-50-CI
Control Interface
Control Interface Cable
Reference Signal
External 10 MHz
Connector Type
N (50 ohm)
