Norsat ULC-2S-75
$1,500.00
Universal LNB Controller
Reference: 10 MHz Injection Port (SMA Connector)
Connector: F Type 75 Ohm
Control Interface: Switch Control Only
Security policy
Delivery policy
Return policy
Norsat ULC-2S-75 Universal LNB Controller with 10 MHz Ref Port
The Norsat ULC-2S-75 is a 75 Ohm LNB controller with F-type connectors and a 10 MHz reference injection port via SMA. It provides 13V/18V output, tone signal, and switch-based control with line length compensation. Built for long-cable SATCOM applications in harsh conditions.
Reference Signal: 10 MHz injection port (SMA Connector)
Output Voltages: 12.5 – 13.5 VDC / 17.3 – 18.7 VDC
Tone Frequency: 20 – 24 kHz
Tone Amplitude: 0.55 – 0.9 Vpp
Control Interface: Switch, cable, LLC (L: 0–0.8 V, H: 2.5–7 V)
Connector Type: 75 Ohm F-Connector
Output VSWR: max. 2.0:1
Output Current: max. 500 mA
Power Supply: +23 to +25 VDC
Current Consumption: 600 mA @ 24 VDC
IP Rating: IP66
Operating Temp: –30°C to +60°C
Dimensions: 130 × 95 × 30 mm
Weight: 0.66 kg
Made in Canada
ULC-2S-75
- Control Interface
- Switch Control
- Reference Signal
- External 10 MHz
- Connector Type
- F (75 ohm)
Specific References
Universal LNB Controller
Reference: 10 MHz Injection Port (SMA Connector)
Connector: F Type 75 Ohm
Control Interface: Switch Control Only
