Norsat BT-1102 L-Band Bias Tee

Norsat BT-1102 L-Band Bias Tee

The Norsat BT-1102 is a compact, weather-sealed L-Band bias tee designed to inject DC power and 10 MHz reference signals into RF lines with minimal loss. Engineered for professional SATCOM systems, it features N-type connectors, IP66 environmental sealing, and low 1 dB insertion loss across 950–2150 MHz, ensuring reliable operation in outdoor and harsh environments.

Frequency Band: L-Band
Pass Band: 950 – 2150 MHz
10 MHz Pass Band: 10 – 100 MHz
Input / Output VSWR: 2.0 : 1 max
Insertion Loss: 1 dB max
Connectors: N-female (RF In, RF Out, 10 MHz In)
DC Connector: None
IP Rating: IP66
Operating Temperature: –30 °C to +50 °C
Storage Temperature: –40 °C to +70 °C
Dimensions (L × W × H): 105 × 55 × 25 mm
Weight: 0.17 kg
Country of Origin: Canada
