Norsat BT-1108 L-Band Bias Tee

Norsat BT-1108 L-Band Bias Tee

The Norsat BT-1108 is a precision L-Band bias tee designed to inject a 10 MHz reference signal and DC power into RF transmission lines with minimal insertion loss. Featuring BNC and N-type connectors, 950–2150 MHz operating bandwidth, and IP66 weatherproofing, it ensures reliable outdoor operation for professional SATCOM and communication systems.

Frequency Band: L-Band
Pass Band: 950 – 2150 MHz
10 MHz Pass Band: 10 – 100 MHz
Insertion Loss: ≤ 1 dB
Input / Output VSWR: 2.0 : 1 max
RF Input Connector: N-female (50 Ω)
Output Connector: N-female (50 Ω)
10 MHz Injection: BNC-female (50 Ω)
DC Connector: None
IP Rating: IP66
Operating Temperature: –30 °C to +50 °C
Storage Temperature: –40 °C to +70 °C
Dimensions (L × W × H): 105 × 55 × 25 mm
Weight: 0.17 kg
Country of Origin: Canada
ECCN: EAR99
