Norsat BT-1109 L-Band Bias Tee

Norsat BT-1109 L-Band Bias Tee

The Norsat BT-1109 is a high-reliability L-Band bias tee designed to inject a 10 MHz reference and DC power into RF lines with minimal loss. It features wide 950–2150 MHz bandwidth, TNC-female reference port, and N-female 50 Ω RF interfaces in a rugged IP66 sealed housing for outdoor SATCOM and teleport deployments.

Frequency Band: L-Band
Pass Band: 950 – 2150 MHz
10 MHz Pass Band: 10 – 100 MHz
Insertion Loss: ≤ 1 dB
VSWR (Input/Output): 2.0 : 1 max
RF Connectors: N-female (50 Ω)
10 MHz Injection Port: TNC-female
DC Connector: None
IP Rating: IP66
Operating Temperature: –30 °C to +50 °C
Storage Temperature: –40 °C to +70 °C
Dimensions (L × W × H): 105 × 55 × 25 mm
Weight: 0.17 kg
Country of Origin: Canada
ECCN: EAR99
