Norsat BT-1110 L-Band Bias Tee
$541.00
• IF Connector: N-Female (50 Ω)
• BUC/LNB Connector: N-Female (50 Ω)
• DC Connector: N-Female (50 Ω)
• 10 MHz Injection Port: No Connector (10 MHz Pass through)
Security policy
Delivery policy
Return policy
Norsat BT-1110 L-Band Bias Tee
The Norsat BT-1110 is a robust L-Band bias tee engineered to pass RF signals while injecting DC power into the transmission line with minimal insertion loss. It features N-female 50 Ω connectors for RF input, output, and DC port, offering IP66 protection and reliable performance for SATCOM and teleport infrastructure.
Frequency Band: L-Band
Pass Band: 950 – 2150 MHz
Insertion Loss: ≤ 1 dB
Input VSWR: 2.0 : 1 max Output VSWR: 2.0 : 1 max
10 MHz Injection: None
RF Input Connector: N-female (50 Ω)
Output Connector: N-female (50 Ω)
DC Connector: N-female (50 Ω)
IP Rating: IP66
Operating Temperature: –30 °C to +50 °C
Storage Temperature: –40 °C to +70 °C
Dimensions (L × W × H): 105 × 55 × 25 mm
Weight: 0.17 kg
Country of Origin: Canada
ECCN: EAR99
BT-1110
- IF Connector
- N (Female) - 50 Ohm
- BUC / LNB Connector
- N (Female) - 50 Ohm
- DC Connector
- N (Female) - 50 Ohm
- 10 MHz Injection
- 10 MHz Pass Through
Specific References
• IF Connector: N-Female (50 Ω)
• BUC/LNB Connector: N-Female (50 Ω)
• DC Connector: N-Female (50 Ω)
• 10 MHz Injection Port: No Connector (10 MHz Pass through)
