Norsat BT-1113 L-Band Bias Tee

Norsat BT-1113 L-Band Bias Tee

The Norsat BT-1113 is a rugged L-Band bias tee that combines DC power and 10 MHz reference injection through RF lines with minimal loss. It features SMA-female 10 MHz port and N-female 50 Ω RF and DC ports, offering reliable operation across 950–2150 MHz with IP66 environmental protection for outdoor SATCOM systems.

Frequency Band: L-Band

Pass Band: 950 – 2150 MHz
10 MHz Pass Band: 10 – 100 MHz
Insertion Loss: ≤ 1 dB
Input / Output VSWR: 2.0 : 1 max
RF Input Connector: N-female (50 Ω)
Output Connector: N-female (50 Ω)
DC Connector: N-female (50 Ω)
10 MHz Injection: SMA-female (50 Ω)
IP Rating: IP66
Operating Temperature: –30 °C to +50 °C
Storage Temperature: –40 °C to +70 °C
Dimensions (L × W × H): 105 × 55 × 25 mm
Weight: 0.17 kg
Country of Origin: Canada
ECCN: EAR99
