Norsat BT-1120 L-Band Bias Tee
$541.00
• IF Connector: N-Female (50 Ω)
• BUC/LNB Connector: N-Female (50 Ω)
• DC Connector: F-Female (75 Ω)
• 10 MHz Injection Port: No Connector (10 MHz Pass through)
Security policy
Delivery policy
Return policy
Norsat BT-1120 L-Band Bias Tee
The Norsat BT-1120 is a high-reliability L-Band bias tee designed for professional SATCOM systems requiring DC power injection without 10 MHz reference feed. It features N-female 50 Ω RF connectors and an F-female 75 Ω DC port, delivering excellent performance over 950–2150 MHz with ≤ 1 dB insertion loss in a compact IP66-rated enclosure.
Frequency Band: L-Band
Pass Band: 950 – 2150 MHz
Insertion Loss: ≤ 1 dB
Input VSWR: 2.0 : 1 max Output VSWR: 2.0 : 1 max
10 MHz Injection: No connector
DC Connector: F-female (75 Ω)
RF Input / Output: N-female (50 Ω)
IP Rating: IP66
Operating Temperature: –30 °C to +50 °C
Storage Temperature: –40 °C to +70 °C
Dimensions (L × W × H): 105 × 55 × 25 mm
Weight: 0.17 kg
Country of Origin: Canada
ECCN: EAR99
BT-1120
- IF Connector
- N (Female) - 50 Ohm
- BUC / LNB Connector
- N (Female) - 50 Ohm
- DC Connector
- F (Female) - 75 Ohm
- 10 MHz Injection
- 10 MHz Pass Through
Specific References
• IF Connector: N-Female (50 Ω)
• BUC/LNB Connector: N-Female (50 Ω)
• DC Connector: F-Female (75 Ω)
• 10 MHz Injection Port: No Connector (10 MHz Pass through)
