Norsat BT-1122 L-Band Bias Tee

Norsat BT-1122 L-Band Bias Tee

The Norsat BT-1122 is a precision L-Band bias tee designed for SATCOM and broadcast systems that require both DC and 10 MHz reference injection. It features N-female 50 Ω RF connectors and F-female 75 Ω DC and 10 MHz ports, offering minimal insertion loss across 950–2150 MHz in a compact IP66-sealed design.

Frequency Band: L-Band
Pass Band: 950 – 2150 MHz
10 MHz Pass Band: 10 – 100 MHz
Insertion Loss: ≤ 1 dB
Input / Output VSWR: 2.0 : 1 max
10 MHz Injection: F-female (75 Ω)
DC Connector: F-female (75 Ω)
RF Input / Output: N-female (50 Ω)
IP Rating: IP66
Operating Temperature: –30 °C to +50 °C
Storage Temperature: –40 °C to +70 °C
Dimensions (L × W × H): 105 × 55 × 25 mm
Weight: 0.17 kg
Country of Origin: Canada
ECCN: EAR99
