Norsat BT-3282 L-Band Bias Tee

$541.00

• Pass Band: 950 - 1450 MHz

• IF Connector: SMA-Female (50 Ω)

• BUC/LNB Connector: F-Female (75 Ω)

• DC Connector: BNC-Female

• 10 MHz Injection Port: F-Female (75 Ω)

Quantity

Standard lead time: 2 - 3 Weeks. Contact sales for faster shipping or availability.

Security policy

Delivery policy

Return policy

Norsat BT-3282 L-Band Bias Tee

The Norsat BT-3282 is a rugged L-Band bias tee for 950–1450 MHz applications, featuring a BNC-female DC input and F-female 10 MHz injection port. With ≤1 dB insertion loss and 2.0:1 VSWR, it ensures reliable RF, DC power, and reference signal distribution. Its IP66-rated outdoor housing is built for long-term SATCOM and RF system durability.

Frequency Band: 950–1450 MHz
10 MHz Pass Band: 10–100 MHz
Insertion Loss: ≤1 dB
VSWR: 2.0:1 max
10 MHz Port: F (F), 75 Ω
DC Port: BNC (F)
RF Input Connector: SMA (F), 50 Ω
RF Output Connector: F (F), 75 Ω
IP Rating: IP66
Temp Range: –30 °C to +50 °C
Weight: 0.17 kg
Origin: Canada
