Norsat BT-3298 L-Band Bias Tee

$541.00

• Pass Band: 950 - 1450 MHz

• IF Connector: SMA-Female (50 Ω)

• BUC/LNB Connector: F-Female (75 Ω)

• DC Connector: TNC-Female

• 10 MHz Injection Port: BNC-Female

Quantity

Standard lead time: 2 - 3 Weeks. Contact sales for faster shipping or availability.

Security policy

Delivery policy

Return policy

Norsat BT-3298 L-Band Bias Tee

The Norsat BT-3298 is a compact L-Band bias tee for 950–1450 MHz applications, featuring a TNC-female DC input and BNC-female 10 MHz injection. With ≤1 dB insertion loss and 2.0:1 VSWR, it ensures reliable RF, DC, and reference distribution. Its IP66-rated outdoor enclosure supports stable operation in harsh SATCOM environments.

Frequency Band: 950–1450 MHz

10 MHz Pass Band: 10–100 MHz
Insertion Loss: ≤1 dB
VSWR: 2.0:1 max
10 MHz Port: BNC (F)
DC Port: TNC (F)
RF Input Connector: SMA (F), 50 Ω
RF Output Connector: F (F), 75 Ω
IP Rating: IP66
Temp Range: –30 °C to +50 °C
Weight: 0.17 kg
Origin: Canada
