Norsat BT-3299 L-Band Bias Tee

$541.00

• Pass Band: 950 - 1450 MHz

• IF Connector: SMA-Female (50 Ω)

• BUC/LNB Connector: F-Female (75 Ω)

• DC Connector: TNC-Female

• 10 MHz Injection Port: TNC-Female

Quantity

Standard lead time: 2 - 3 Weeks. Contact sales for faster shipping or availability.

Security policy

Delivery policy

Return policy

Norsat BT-3299 L-Band Bias Tee

The Norsat BT-3299 is a rugged L-Band bias tee operating from 950–1450 MHz, equipped with TNC-female DC input and TNC-female 10 MHz injection. Offering ≤1 dB insertion loss and 2.0:1 VSWR, it provides stable RF, DC power, and timing-reference distribution. Its compact, IP66-rated enclosure is built for demanding SATCOM and RF system deployments.

Frequency Band: 950–1450 MHz

10 MHz Pass Band: 10–100 MHz
Insertion Loss: ≤1 dB
VSWR: 2.0:1 max
10 MHz Port: TNC (F)
DC Port: TNC (F)
RF Input Connector: SMA (F), 50 Ω
RF Output Connector: F (F), 75 Ω
IP Rating: IP66
Temp Range: –30 °C to +50 °C
Weight: 0.17 kg
Origin: Canada
