Norsat BT-3323 L-Band Bias Tee
$541.00
• Pass Band: 950 - 2150 MHz
• IF Connector: SMA-Female (50 Ω)
• BUC/LNB Connector: SMA-Female (50 Ω)
• DC Connector: F-Female (75 Ω)
• 10 MHz Injection Port: SMA-Female (50 Ω)
Security policy
Delivery policy
Return policy
Norsat BT-3323 L-Band Bias Tee
The Norsat BT-3323 is a compact L-Band bias tee supporting 950–2150 MHz, equipped with an F-female DC input and SMA-female 10 MHz injection. Offering ≤1 dB insertion loss and 2.0:1 VSWR, it ensures reliable RF, DC, and reference signal routing. Its IP66-rated outdoor construction makes it ideal for SATCOM terminal and RF system integration.
Frequency Band: 950–2150 MHz
10 MHz Pass Band: 10–100 MHz
Insertion Loss: ≤1 dB
VSWR: 2.0:1 max
10 MHz Port: SMA (F), 50 Ω
DC Port: F (F), 75 Ω
RF Input/Output: SMA (F), 50 Ω
IP Rating: IP66
Temp Range: –30 °C to +50 °C
Weight: 0.17 kg
Origin: Canada
ECCN: EAR99
HTS: 8517690000
BT-3323
- Passband
- 950-2150 MHz
- IF Connector
- SMA (Female) - 50 Ohm
- BUC / LNB Connector
- SMA (Female) - 50 Ohm
- DC Connector
- F (Female) - 75 Ohm
- 10 MHz Injection
- SMA (Female) - 50 Ohm
Specific References
• Pass Band: 950 - 2150 MHz
• IF Connector: SMA-Female (50 Ω)
• BUC/LNB Connector: SMA-Female (50 Ω)
• DC Connector: F-Female (75 Ω)
• 10 MHz Injection Port: SMA-Female (50 Ω)
