Norsat BT-3381 L-Band Bias Tee
$541.00
• Pass Band: 950 - 2150 MHz
• IF Connector: SMA-Female (50 Ω)
• BUC/LNB Connector: SMA-Female (50 Ω)
• DC Connector: BNC-Female
• 10 MHz Injection Port: N-Female (50 Ω)
Security policy
Delivery policy
Return policy
Norsat BT-3381 L-Band Bias Tee
The Norsat BT-3381 is an outdoor-rated L-Band bias tee supporting 950–2150 MHz, featuring SMA-female RF ports, BNC-female DC input, and N-female 10 MHz injection. Delivering ≤1 dB insertion loss and 2.0:1 VSWR, it provides stable RF, DC, and reference distribution for SATCOM and communication systems.
Frequency Band: 950–2150 MHz
10 MHz Pass Band: 10–100 MHz
Insertion Loss: ≤1 dB
VSWR: 2.0:1 max
10 MHz Port: N (F), 50 Ω
DC Port: BNC (F)
RF Input/Output: SMA (F), 50 Ω
IP Rating: IP66
Temp Range: –30 °C to +50 °C
Weight: 0.17 kg
Origin: Canada
ECCN: EAR99
HTS: 8517690000
BT-3381
- Passband
- 950-2150 MHz
- IF Connector
- SMA (Female) - 50 Ohm
- BUC / LNB Connector
- SMA (Female) - 50 Ohm
- DC Connector
- BNC (Female)
- 10 MHz Injection
- N (Female) - 50 Ohm
Specific References
• Pass Band: 950 - 2150 MHz
• IF Connector: SMA-Female (50 Ω)
• BUC/LNB Connector: SMA-Female (50 Ω)
• DC Connector: BNC-Female
• 10 MHz Injection Port: N-Female (50 Ω)
