Norsat BT-3382 L-Band Bias Tee
$541.00
• Pass Band: 950 - 2150 MHz
• IF Connector: SMA-Female (50 Ω)
• BUC/LNB Connector: SMA-Female (50 Ω)
• DC Connector: BNC-Female
• 10 MHz Injection Port: F-Female (75 Ω)
Security policy
Delivery policy
Return policy
Norsat BT-3382 L-Band Bias Tee
The Norsat BT-3382 is a compact L-Band bias tee designed for 950–2150 MHz operation, featuring SMA-female RF ports, BNC-female DC feed, and 75-ohm F-female 10 MHz injection. With ≤1 dB insertion loss and 2.0:1 VSWR, it ensures stable RF, DC, and reference signal distribution. Housed in an IP66-rated outdoor enclosure, it is ideal for SATCOM terminal and RF chain integration.
Frequency Band: 950–2150 MHz
10 MHz Pass Band: 10–100 MHz
Insertion Loss: ≤1 dB
VSWR: 2.0:1 max
10 MHz Port: F (F), 75 Ω
DC Port: BNC (F)
RF Input/Output: SMA (F), 50 Ω
IP Rating: IP66
Temp Range: –30 °C to +50 °C
Weight: 0.17 kg
Origin: Canada
ECCN: EAR99
HTS: 8517690000
BT-3382
- Passband
- 950-2150 MHz
- IF Connector
- SMA (Female) - 50 Ohm
- BUC / LNB Connector
- SMA (Female) - 50 Ohm
- DC Connector
- BNC (Female)
- 10 MHz Injection
- F (Female) - 75 Ohm
Specific References
• Pass Band: 950 - 2150 MHz
• IF Connector: SMA-Female (50 Ω)
• BUC/LNB Connector: SMA-Female (50 Ω)
• DC Connector: BNC-Female
• 10 MHz Injection Port: F-Female (75 Ω)
