Norsat BT-3383 L-Band Bias Tee
$650.00
• Pass Band: 950 - 2150 MHz
• IF Connector: SMA-Female (50 Ω)
• BUC/LNB Connector: SMA-Female (50 Ω)
• DC Connector: BNC-Female
• 10 MHz Injection Port: SMA-Female (50 Ω)
Security policy
Delivery policy
Return policy
Norsat BT-3383 L-Band Bias Tee
The Norsat BT-3383 is a rugged L-Band bias tee designed for 950–2150 MHz links, featuring SMA-female RF ports, BNC DC feed, and SMA 10 MHz injection. With ≤1 dB insertion loss and 2.0:1 VSWR, it ensures stable RF, DC, and reference distribution. Housed in a compact IP66-rated enclosure, it is ideal for outdoor SATCOM installations.
Frequency Band: 950–2150 MHz
10 MHz Pass Band: 10–100 MHz
Insertion Loss: ≤1 dB
VSWR: 2.0:1 max
10 MHz Port: SMA (F), 50 Ω
DC Port: BNC (F)
RF Input/Output: SMA (F), 50 Ω
IP Rating: IP66
Temp Range: –30 °C to +50 °C
Weight: 0.17 kg
Origin: Canada
ECCN: EAR99
HTS: 8517690000
BT-3383
- Passband
- 950-2150 MHz
- IF Connector
- SMA (Female) - 50 Ohm
- BUC / LNB Connector
- SMA (Female) - 50 Ohm
- DC Connector
- BNC (Female)
- 10 MHz Injection
- SMA (Female) - 50 Ohm
Specific References
• Pass Band: 950 - 2150 MHz
• IF Connector: SMA-Female (50 Ω)
• BUC/LNB Connector: SMA-Female (50 Ω)
• DC Connector: BNC-Female
• 10 MHz Injection Port: SMA-Female (50 Ω)
