MFC 17600

17600-3740 C-Band Bandpass Filter | Narrowband WiMAX Rejection

Designed for precision C-band transponder protection, the MFC 17600-3740 filter provides targeted rejection of nearby WiMAX interference, such as 3710 MHz signals affecting transponder 2. With a 3740 MHz center frequency and narrow 36 MHz passband (±18 MHz), it delivers 20 dB typical rejection just 30 MHz outside the band. Weatherproof and flange-configurable, it’s ideal for outdoor SATCOM setups requiring focused frequency protection.

Key Features:

Center Frequency: 3740 MHz
Passband: 3722–3758 MHz (±18 MHz)
Insertion Loss: ≤1.0 dB
Rejection: Typ. 20 dB @ ±30 MHz
VSWR: ≤1.5:1
Flanges: CPR-229G (input), CPR-229F (output)
Weatherized gray lacquer finish for outdoor use
Available for standard, extended, and super-extended C-band transponders
Applications:
Targeted filtering for C-band transponders in environments with WiMAX or adjacent-band interference.
