MFC 19524

MFC Model 19524 | Multi-Purpose C-Band Receive Filter for Interference Rejection
The model 19524 is a high-performance C-band receive filter that offers wideband interference suppression across multiple sources. With a passband of 3.8–4.2 GHz and rejection up to 80 dB from 5.25 to 10.68 GHz, it protects satellite downlinks from maritime, WiMAX, wireless point-to-multipoint, and radar systems. Ideal for dense RF environments, it features low insertion loss (0.3 dB typ), excellent VSWR, and CPR229G flanges for seamless integration in professional SATCOM systems.

Key Features:

Passband: 3.8–4.2 GHz

Rejection:
≥70 dB @ 3.50 GHz
≥50 dB from 2.0–3.25 GHz & 4.45–5.0 GHz
≥45 dB @ 3.65 GHz
≥80 dB from 5.25–10.68 GHz

Insertion Loss: 0.3 dB typ., 0.6 dB max

VSWR: ≤1.33:1

Flanges: CPR229G

Finish: Black lacquer

Applications: Dense satellite ground stations, maritime & aeronautical interference protection, WiMAX/5G rejection
