MFC 19598

19598 C-Band Bandpass Filter | 3990–4050 MHz | Radar & WiMAX Rejection

The Model 19598 C-Band bandpass filter is engineered to protect the narrow 3990–4050 MHz range from adjacent-band interference such as WiMAX and radar. It delivers excellent rejection with ≥55 dB at 3640 MHz and ≥40 dB at 4400 MHz, making it ideal for focused satellite downlink applications. With low insertion loss, a compact form factor, and CPR229G/F flanges, this filter is optimized for space-limited outdoor installations.

Key Features:

Passband: 3990–4050 MHz
Insertion Loss: ≤0.5 dB
VSWR: ≤1.22:1
Rejection: ≥55 dB @ 3640 MHz, ≥40 dB @ 4400 MHz
Flanges: CPR229G (in) / CPR229F (out)
Compact size: 203 × 98 × 70 mm
Finish: Gloss white lacquer
