ETL Systems Hawk HWK-G2S-21-D832 8×32 Extended L-Band Distribution Matrix

ETL Systems Hawk HWK-G2S-21-D832 8×32 Extended L-Band Distribution Matrix

The ETL Systems Hawk HWK-G2S-21-D832 routes eight extended L-band inputs to 32 outputs for satellite downlink systems. Its adjustable gain and slope, RF input detection, and LNB powering support signal distribution in gateways and teleports with multiple modems.

Frequency Range: 500–2450 MHz
Matrix Capacity: 8 inputs × 32 outputs; distributive
Gain Control: −10 to +15 dB typ., with 0.5 dB step resolution
Slope Control: 0–6 dB in 1 dB steps
LNB Power: 13/18 V DC, up to 400 mA; 0/22 kHz tone
RF Input Detection: 0 to −50 dBm sensing range
RF Ports: 50 Ω SMA, DC blocked
Switching Time: Less than 50 ms
Control & Monitoring: Front-panel touchscreen; Ethernet with HTTPS, SNMPv2/v3, and web interface
Power Supplies: Dual redundant, hot-swappable
Form Factor: 2U, 19-inch rack mount

Key Features

• Distributes eight downlink signals across 32 outputs

• Adjustable gain and slope for signal balancing

• Integrated LNB powering and RF input detection

• Field-replaceable RF matrix module, CPU, and touchscreen
