ETL Systems Hawk HWK-G2S-21-C328 32×8 Extended L-Band Combining Matrix

ETL Systems Hawk HWK-G2S-21-C328 32×8 Extended L-Band Combining Matrix

The ETL Systems Hawk HWK-G2S-21-C328 routes 32 extended L-band inputs to eight outputs for satellite uplink systems. Adjustable gain and slope, RF power sensing, and redundant power supplies make it suitable for gateways and teleports with multiple modems and antenna paths.

Frequency Range: 500–2450 MHz
Matrix Capacity: 32 inputs × 8 outputs; combining
Gain Control: −10 to +15 dB typ., with 0.5 dB step resolution
Slope Control: 0–6 dB in 1 dB steps
RF Power Sensing Range: 0 to −50 dBm
RF Ports: 50 Ω SMA, DC blocked
Switching Time: Less than 50 ms
Control & Monitoring: Front-panel touchscreen; Ethernet with HTTPS, SNMPv2/v3, and web interface
Power Supplies: Dual redundant, hot-swappable
Form Factor: 2U, 19-inch rack mount

Key Features

• Combines signals from 32 inputs into eight routed output paths

• Adjustable gain and slope for signal balancing

• RF power sensing for signal monitoring

• Field-replaceable RF matrix module, CPU, and touchscreen
