ETL Systems Dextra 22473 Dual 8-Way IF-Band Active Splitter

ETL Systems Dextra 22473 Dual 8-Way IF-Band Active Splitter

The ETL Systems Dextra 22473 contains two 8-way active splitters for distributing IF-band signals from 50–1000 MHz in a 1U chassis. It includes a −20 dB front-panel monitoring port, Ethernet control and monitoring, and dual redundant power supplies.

Frequency Range: 50–1000 MHz
Splitter Capacity: Two independent 1-input × 8-output splitters
Gain: 0 ± 1.2 dB, mean across band
Gain Flatness: ±1.5 dB across the full band; ±0.3 dB across any 36 MHz
Monitor Port: Front-panel 50 Ω SMA, −20 dB
Isolation: 30 dB typ. at 70 MHz; 21 dB typ. at 1000 MHz
Control & Monitoring: Ethernet with web interface, SNMP and ETL TCP protocol; front-panel status LEDs
Power Supplies: Dual redundant, with separate IEC inlets
Form Factor: 1U, 19-inch rack mount

Key Features

• Distributes two IF signals to eight outputs each

• Provides a front-panel port for signal monitoring

• Supports remote status and alarms through Ethernet

• Available with optional hot/cold standby redundant amplifiers (OPT-R)

The listed RF specifications apply to the 50 Ω SMA version. The datasheet specifies no LNB power for this model; confirm connector and amplifier options when ordering.
