ETL Systems Dextra 22474 16-Way IF-Band Active Splitter with LNB Power

ETL Systems Dextra 22474 16-Way IF-Band Active Splitter with LNB Power

The ETL Systems Dextra 22474 is a 16-way active IF-band splitter for distributing one signal from 50–1000 MHz. It combines a −20 dB front-panel monitor port, remotely configurable LNB power, Ethernet monitoring, and dual redundant power supplies in a 1U chassis.

Frequency Range: 50–1000 MHz
Splitter Capacity: 1 input × 16 outputs
Gain: 0 ± 1.0 dB, mean across band
Gain Flatness: ±1.0 dB across the full band; ±0.25 dB across any 36 MHz
Monitor Port: Front-panel 50 Ω SMA, −20 dB
LNB Power: 0/13/18 V DC, up to 500 mA through the common input port; 22 kHz tone on/off
Control & Monitoring: Ethernet with web interface, SNMP and ETL TCP protocol; front-panel status LEDs
Power Supplies: Dual redundant, with separate IEC inlets
Form Factor: 1U, 19-inch rack mount

Key Features

• Distributes one IF-band signal to 16 outputs

• Allows remote setting of LNB voltage, 22 kHz tone and current alarm threshold

• Provides a front-panel port for signal monitoring

• Available with optional hot/cold standby redundant amplifiers (OPT-R)

The listed RF specifications apply to the 50 Ω SMA version. Confirm connector and amplifier options when ordering.
