ETL Systems GENUS DIV-G3-S2-805 8-Way L-Band Active Splitter

ETL Systems GENUS DIV-G3-S2-805 8-Way L-Band Active Splitter

The ETL Systems DIV-G3-S2-805 is an 8-way active L-band splitter module for the 3U GENUS chassis. It distributes signals across 850–2500 MHz, with adjustable gain and slope, amplifier redundancy, RF detection, and LNB powering for satellite ground systems.

Frequency Range: 850–2500 MHz
Splitter Capacity: 1 input, 8 outputs
Gain: 0 to 24 dB nominal, adjustable in 0.25 dB steps
Slope Control: 0 to 8 dB in 1 dB steps
RF Detection: 0 to −40 dBm input detection range
LNB Power: Selectable 13 V or 18 V with optional 22 kHz tone; up to 450 mA
Amplifier Redundancy: 1:1 automatic switchover with cold standby amplifier
Chassis Compatibility: 3U GENUS; occupies two module slots
Connector Options: 50 Ω SMA, 50 Ω BNC, 75 Ω BNC, or 75 Ω F-type

Key Features

• Variable gain and slope help balance signal levels.

• Field-serviceable module can be inserted while the GENUS shelf is in service.

• Local and remote control are provided through the selected chassis.

Confirm the connector configuration when ordering.
