ETL Systems 22280 LD Series 16-Way L-Band Active Combiner

ETL Systems 22280 LD Series 16-Way L-Band Active Combiner

The ETL Systems 22280 LD Series is a 16-way active L-band combiner in a 1U rackmount chassis. It combines signals across 850–2150 MHz and includes dual redundant power supplies with front-panel status monitoring.

Frequency Range: 850–2150 MHz
Combiner Capacity: 16 inputs, 1 output
Gain: 0 ±1.5 dB
Input Isolation: 25 dB
Connector Options: 50 Ω BNC, 50 Ω SMA, 75 Ω F-type, or 75 Ω BNC
Power Supplies: Dual redundant with two IEC AC inlets
AC Input: 85–264 V AC, 50–60 Hz
Monitoring: Front-panel PSU status LEDs
Form Factor: 1U, 19-inch rackmount

Key Features

• Combines 16 L-band inputs into one output.

• Dual redundant power supplies support system resilience.

• Multiple connector and impedance configurations are available.

Confirm the required RF connector and impedance configuration when ordering.
