ETL Systems DEXTRA 22513 Dual 4-Way S-Band Active Splitter

ETL Systems DEXTRA 22513 Dual 4-Way S-Band Active Splitter

The ETL Systems DEXTRA 22513 distributes two RF input signals to two independent groups of four outputs across 850–3150 MHz. This compact 1U active splitter includes switchable LNB powering, −20 dB front-panel signal monitoring, Ethernet control, and dual redundant power supplies.

Frequency Range: 850–3150 MHz
Capacity: Dual 4-way splitters; two inputs and eight outputs total
Gain: 0 ±1.5 dB mean across band
Front-Panel Monitor: −20 dB, 50 Ω SMA
LNB Power: Selectable 0/13/18 V DC, up to 500 mA via the common RF input; 22 kHz tone on/off
Control & Monitoring: Ethernet with web browser access, SNMP, and adjustable LNB current alarm thresholds
Power Supplies: Dual redundant AC supplies
Form Factor: 1U, 19-inch rack mount

Key Features

• Provides two independent 4-way RF distribution paths

• Covers L-band and S-band frequencies

• Supports remote LNB voltage and tone control

• Includes front-panel status LEDs and dry-contact PSU and LNB supply alarms

Published RF specifications apply to the 50 Ω SMA version; other variants may differ.
