ETL Systems Swift SWF-G2S-K2-238 32×1 DC–26 GHz RF Switch Module

ETL Systems Swift SWF-G2S-K2-238 32×1 DC–26 GHz RF Switch Module

The ETL Systems Swift SWF-G2S-K2-238 provides 32×1 RF signal selection over DC–26 GHz in a compatible GENUS 2U chassis. This SP32T absorptive coaxial switch module features 50 Ω SMA ports and insertion loss below 4 dB. Occupying 17 chassis slots, it supports local touchscreen control and remote operation through the parent chassis Ethernet interface.

Frequency Range: DC–26 GHz
Switch Configuration: 32×1, SP32T
Switch Type: Absorptive
RF Ports: SMA, 50 Ω
Insertion Loss: <4.0 dB; generally increases with frequency
Flatness: ±1.5 dB
Return Loss: 15 dB typ.; 10 dB minimum
RF Input Power Limit: 1 W per input; 3 W total per switch, limited by internal terminators
Module Power Consumption: 15 W maximum at steady state
Control & Monitoring: Through the parent chassis HMI and RJ45 Ethernet interface with web browser and SNMP
Alarms: Via Ethernet
Module Width: 17 GENUS 2U chassis slots
Operating Temperature: 0°C to +45°C
Weight: 6 kg
Installation: Indoor use within a compatible GENUS 2U chassis

Key Features

• 32×1 RF signal selection with SP32T switching

• Wideband coverage from DC to 26 GHz

• Absorptive switch design with 50 Ω SMA ports

• Insertion loss below 4 dB

• Local touchscreen and remote Ethernet control through the parent chassis

Requires a compatible GENUS 2U chassis with 17 slots available. Specifications are preliminary, and a minimum order quantity applies. Please confirm configuration and order requirements when requesting a quotation.
