ETL Systems CST-POE-SW08-1083 8-Way Broadband PoE Smart RF Switch

ETL Systems CST-POE-SW08-1083 8-Way Broadband PoE Smart RF Switch

The ETL Systems CST-POE-SW08-1083 is an eight-way broadband smart RF switch covering 10–3000 MHz, supporting either 1×8 signal routing or 8×1 signal selection. Its compact enclosure receives power and remote control through an RJ45 Ethernet port, with web browser, SNMP and TCP/IP control and an LED indicating the selected switch path.

Frequency Range: 10–3000 MHz
Switch Configuration: 1×8 or 8×1
Impedance: 50 Ω
RF Ports: SMA
Insertion Loss, Maximum: 6.0 dB across 850–2150 MHz; 6.5 dB across 10–3000 MHz, subject to manufacturer confirmation
Input Return Loss: 20 dB typ., 14 dB minimum across 850–2150 MHz; 16 dB typ., 12 dB minimum across 10–3000 MHz
Output Return Loss: 20 dB typ., 14 dB minimum across 850–2150 MHz; 16 dB typ., 12 dB minimum across 10–3000 MHz
Isolation: 60 dB across 850–2150 MHz; 55 dB across 10–3000 MHz, input-to-output and input-to-input
In-Band Spurious: <−95 dBm maximum; <−105 dBm typ.
Out-of-Band Spurious: <−80 dBm maximum, as listed in the datasheet
Maximum RF Input Power: +10 dBm (10 mW)
Power Supply: IEEE 802.3af-compliant PoE, 44–57 V
Power Consumption: 6 W maximum
Remote Control: RJ45 Ethernet with web browser, SNMP and TCP/IP
Status Indicator: LED showing the selected switch path
Mounting Options: Through-hole mounting or tapped holes for chassis mounting
Operating Temperature: 0°C to +45°C
Installation: Indoor use only

Key Features

• Eight-way RF switching across 10–3000 MHz

• Supports 1×8 routing or 8×1 signal selection

• Power and remote control through one Ethernet connection

• Web browser, SNMP and TCP/IP control

• LED indication of the selected signal path

• Compact, rugged enclosure with mounting options

Requires an IEEE 802.3af-compatible PoE power source. Please confirm insertion-loss and flatness specifications when requesting a quotation.
