ETL Systems GRIFFIN GRF-087 ASI/SDI Redundancy Switch Module

ETL Systems GRIFFIN GRF-087 ASI/SDI Redundancy Switch Module

The ETL Systems GRIFFIN GRF-087 provides 2×1 ASI/SDI redundancy switching with an integrated 1:3 distribution amplifier, delivering the selected input signal to three outputs. Supporting ASI, SD-SDI, HD-SDI and 3G-SDI signals, it offers automatic switchover based on carrier presence and manual path selection. Its non-latching switch design includes a failsafe bypass, and the module occupies one slot in a compatible GRIFFIN chassis.

Model Configuration: GRF-087-B7B7
Switch Configuration: 2×1 redundancy switch; not bidirectional
Port Capacity: Two inputs, three outputs
Output Distribution: Integrated 1:3 distribution amplifier
Supported Signal Types: ASI, SD-SDI, HD-SDI and 3G-SDI
Connectors: BNC, 75 Ω
Switch Type: Non-latching with failsafe bypass
Automatic Switching: Based on carrier presence
Manual Switching: Available
Input Level: 300–800 mV
Output Level: >600 mV
On/Off Isolation: >50 dB
Module Slots Used: One
Installation: Within a compatible GRIFFIN chassis

Key Features

• Automatic redundancy switching between two ASI/SDI inputs

• Three outputs from an integrated distribution amplifier

• Supports ASI through 3G-SDI signal types

• Carrier-presence detection for automatic switchover

• Non-latching switch with failsafe relay and amplifier bypass

• Manual signal-path selection

Requires a compatible GRIFFIN chassis. Specify GRF-087-B7B7 when requesting a quotation for the 75 Ω BNC configuration.
