DTV Innovations TSACO-3000 Automatic Failover Switch

DTV Innovations TSACO-3000 ASI/310M/TSoIP Automatic Failover Switch

The DTV Innovations TSACO-3000 combines a professional transport-stream automatic failover switch with ASI, SMPTE-310M and Transport Stream over IP conversion. Designed for terrestrial, cable and satellite broadcast systems, it is compliant with ATSC and DVB standards and supports ATSC Mobile DTV applications.

The TSACO-3000 automatically monitors primary and backup transport streams and switches sources when a user-configurable failure condition is detected. Seamless switching maintains synchronization during the transition, helping prevent connected receivers from losing lock. Primary and backup inputs accept ASI, SMPTE-310M or TSoIP, with automatic input-format and packet-size detection.

All three output formats remain active simultaneously, allowing the unit to perform format conversion as well as failover protection. SMPTE 2022 support includes UDP or RTP encapsulation, de-encapsulation and forward error correction. Web-based management, SNMP monitoring, GPIO, relay bypass, dual power supplies and an optional four-input failover mode provide flexible and dependable broadcast operation.

Key Features

• Automatic transport-stream failover switching

• Integrated ASI, SMPTE-310M and TSoIP format conversion

• Primary and backup inputs accept ASI, SMPTE-310M or TSoIP

• ASI, SMPTE-310M and TSoIP outputs active simultaneously

• Seamless switching maintains receiver synchronization

• Automatic input-format and packet-size detection

• SMPTE 2022 transport stream over IP support

• UDP and RTP transport-stream encapsulation

• UDP/RTP de-encapsulation

• Forward error correction support

• Supports 188-byte and 204-byte transport-stream packets

• Configurable 1 to 7 transport-stream packets per IP packet

• FEC matrix configuration support

• Compliant with ATSC and DVB standards

• ATSC Mobile DTV ready

• Fourteen configurable failover trigger parameters

• Configurable automatic return to the primary input

• Optional four-input failover switching mode

• Integrated web-server configuration and monitoring

• Remote input selection and status indication

• SNMP remote monitoring

• Manual front-panel input selection and reset control

• Front-panel status and error indicators

• Relay bypass on the primary input

• Rear-panel GPIO connector

• Save and load user-defined configurations

• User login management controls

• ASI data rates up to 216 Mbps

• SMPTE-310M data rate of 19.392658 Mbps

• Single 100/1000BASE-TX Ethernet management port

• Dual power supplies for increased reliability

• Field-upgradable architecture

• Compact 1 RU rack-mount chassis

• Maximum power consumption of 25 W

• Made in the USA
