ESAT-2PD00508N 2-Way Power Divider 0.5–8 GHz, N-Female

The ESAT-2PD00508N is a high-performance 2-way power divider covering 500 MHz to 8 GHz, ideal for Cellular, PCS, and WiMAX applications. Housed in a rugged aluminum enclosure with tri-alloy plated N-female connectors, it offers excellent return loss, low insertion loss, and superior port isolation. Perfect for indoor RF signal distribution, including Wi-Fi 6E and UHF bands.

Frequency Range: 500 MHz to 8 GHz
Insertion Loss: typ. 0.5 dB above 3 dB split
Isolation: typ. 21 dB (600–8000 MHz)
Return Loss: typ. 18 dB (Port S), 22 dB (Ports 1–2)
Amplitude Balance: typ. 0.4 dB
Phase Balance: typ. 2°
Power Handling: up to 20 W CW
Connectors: N-Female, tri-alloy plated
Dimensions: 4.75 x 1.96 x 0.75 in
Environment: Indoor use only, -55 to +85°C
Compliance: RoHS & REACH
