ESAT-4PD006074S1

4-Way Power Divider

0.6–7.4 GHz

SMA Female

(Front Side Connectors)

Quantity

Request for Quotation

Security policy

Delivery policy

Return policy

ESAT-4PD006074S1 4-Way Power Divider, 0.6–7.4 GHz, SMA-Female

The ESAT-4PD006074S1 is a front-mountable 4-way power divider with SMA connectors, covering 600 MHz to 7.4 GHz. Designed for extended Wi-Fi and WiMAX testing, it offers excellent return loss, tight amplitude and phase balance, and a compact form for rack-mounted RF systems.

Frequency Range: 0.6 – 7.4 GHz
Impedance: 50 Ohm
Return Loss (Port S / Ports 1–4): typ. 17 dB / 19 dB
Insertion Loss (above 6.02 dB): typ. 1.7 dB (max. 2.4 dB)
Isolation: typ. 20 dB
Amplitude Balance: typ. ±0.2 dB
Phase Balance: typ. ±2.5°
Input Power (CW): max. 30 W
Connector Type: SMA Female (Front Mount)
Operating Temp: –40°C to +85°C
Storage Temp: –55°C to +100°C
Weight: approx. 170 g
Finish: Green Paint
RoHS Compliant: Yes
