ESAT-8PD203000MSMP 8-Way Power Divider, 20–3000 MHz, SMP Male
The ESAT-8PD203000MSMP is an 8-way power divider operating from 20 to 3000 MHz with compact SMP male connectors. Designed for high-density indoor RF systems, it offers low insertion loss, high isolation, and excellent amplitude balance in a recessed aluminum housing.
Frequency Range: 20 – 3000 MHz
Impedance: 50 Ohm
Return Loss: typ. 13.4 dB (Port S), typ. 13.7 dB (Ports 1–8)
Insertion Loss: typ. 4.1 dB (above 9.03 dB theoretical), max. 5.7 dB
Isolation: typ. 19.3 dB, min. 14 dB
Amplitude Balance: typ. ±0.45 dB, max. ±0.80 dB
Input Power (CW): max. 1 W
Connector Type: SMP Male (full detent)
Operating Temp: –55°C to +85°C
Storage Temp: –55°C to +100°C
Humidity: 10–90% non-condensing
Environment: Indoor use only
Weight: approx. 170 g (6 oz)
Enclosure: Aluminum with recessed cover
Finish: Clear chemical film
RoHS & REACH Compliant
Made in: USA
