Quintech LC122150A1FAA000 950-2150 MHz 12-Way Active L-Band Combiner

Quintech LC122150A1FAA000 950-2150 MHz 12-Way Active L-Band Combiner

The Quintech LC122150A1FAA000 LC12 2150A is a commercial-quality 12-way active L-band combiner designed to combine as many as 12 satellite IF signals into a single output over the 950-2150 MHz frequency range. Its integrated amplification provides zero nominal insertion loss while maintaining consistent signal levels, impedance matching, isolation, and repeatable performance across all RF ports.

The LC122150A1FAA000 is ideal for satellite ground stations, broadcast facilities, monitoring systems, test laboratories, and other RF signal-distribution applications requiring multiple L-band inputs to be combined into one output. The unit is housed in a compact 1 RU rackmount chassis with 75-ohm Type F connectors.

Specifications:

Product Type: 12-Way Active L-Band Combiner
Manufacturer: Quintech Electronics
Product Series: LC12 2150A
Part Number: LC122150A1FAA000
Frequency Range: 950-2150 MHz
Configuration: 12 Inputs, 1 Output
Impedance: 75 ohms
P1dB: -2 dBm per input
Insertion Loss: 0 dB ±2 dB
Frequency Response: ±2 dB
Isolation: 18 dB
Input Return Loss: 12 dB
Output Return Loss: 12 dB
Noise Figure: 19 dB
RF Connectors: Type F, 75 ohms
Power Requirements: 18-24 VDC at 1 A
Power Connection: 2-pin quick-connect barrier strip
Power Consumption: 12 W
Mounting: 1 RU rackmount
Dimensions: 1.75 in. H × 19 in. W × 6.5 in. D
Net Weight: 2.5 lb.
Gross Boxed Weight: 5 lb.
Certifications: CE, NRTL/TUV and FCC Part 15
Country of Manufacture: USA

Important: All unused RF input ports must be fitted with 75-ohm terminations.

Available now at Esatcom Inc. Please contact us for pricing and lead time.
