DTV Innovations OX-1 Secure Reliable IP Streaming Appliance

DTV Innovations OX-1 Secure Reliable IP Streaming Appliance

The DTV Innovations OX-1 is a compact, secure and reliable IP streaming appliance supporting SRT, Zixi, RIST and SMPTE 2022 protocols. It provides low-latency media transport over busy LANs, public Internet connections, microwave links and other unpredictable IP networks.

Configured as a sender, the OX-1 accepts an MPEG transport stream over IP, encrypts the content and encapsulates it using the selected reliable streaming protocol. As a receiver, it reverses the process to recover the original transport stream. The appliance supports unicast and multicast delivery, streaming rates up to 150 Mbps, as many as eight licensed inputs and up to four output streams per input.

An optional ASI interface enables ASI-to-TSoIP and TSoIP-to-ASI conversion. Separate Gigabit Ethernet data and management ports, AES encryption, ATSC 3.0 STLTP support, SMPTE 2022 forward error correction, SNMP monitoring and integrated web-based management make the OX-1 ideal for compact broadcast contribution and distribution systems.

Key Features

• Compact, secure, low-latency IP streaming appliance

• Supports SRT, Zixi, RIST and SMPTE 2022

• ATSC 3.0 STLTP transport over RIST or SRT

• Configurable as a source/sender or destination/receiver

• Supports unicast and multicast streaming

• UDP and RTP transport support

• SMPTE 2022-1 and SMPTE 2022-2 support

• SMPTE 2022 forward error correction

• AES 128-bit and 256-bit encryption with RIST

• AES 128-bit, 192-bit and 256-bit encryption with SRT

• IP streaming rates up to 150 Mbps

• Licensable for as many as eight inputs

• Up to four output streams per input

• Two configurable Gigabit Ethernet ports

• Separate data and management Ethernet interfaces

• Accepts MPEG transport stream over IP

• Optional ASI input and output interface

• ASI-to-TSoIP and TSoIP-to-ASI conversion

• ASI burst rates up to 213 Mbps

• Integrated web-server configuration and monitoring

• Account- and password-protected management

• SNMP remote monitoring

• Front-panel power, mode, status and input indicators

• HDMI and USB secondary control interfaces

• Compact dimensions of 1.75 × 4.63 × 9.63 inches

• External 12 VDC power supply with locking connector

• Forced-air front-to-rear cooling

• One-year standard warranty

• Optional extended warranty

• Made in the USA
