CPI T07XO-A1

CPI 750W X-Band Outdoor TWTA – Model T07XO-A1

Engineered for Satellite Communications Uplink Applications

The CPI Model T07XO-A1 delivers 750 watts of output power in a rugged, compact, and weatherproof package. Designed for uplink operations in the 7.9 to 8.4 GHz X-Band frequency range, it is fully digital-ready and ideal for both fixed and transportable earth station installations.

Key Features

Efficient and Cost-Effective
Utilizes a high-efficiency, dual-depressed collector helix traveling wave tube (TWT), minimizing energy consumption and reducing overall operating costs.

Exceptional Reliability
Built to withstand extreme environmental conditions. CAN-Bus architecture enhances system reliability and noise immunity. Optional LifeExtender™ technology significantly prolongs TWT lifespan.

User-Friendly Operation
Features a microprocessor-based control system with integrated Ethernet interface. Digital metering, pin diode attenuation, and optional integrated linearizer ensure excellent intermodulation performance. Supports SNMP (v1, v2, v3) for advanced monitor and control (M&C) integration.

Low Maintenance Design
Modular construction and built-in fault diagnostics allow for remote monitoring, quick servicing, and minimal downtime.

Global Compliance
Certified to international safety and EMC standards, including EN-60215 (safety), 2014/30/EU (EMC), and EN-61000-3-2 (harmonics). CE Marked for global market access.

Trusted Worldwide Support
Backed by over four decades of satellite communications expertise and CPI’s 24/7 global support infrastructure, with more than 20 regional service centers.

Assured Quality
Manufactured under ISO 9001:2015 certified quality management systems for consistent performance and product reliability.

Available Options

• Remote control panel

• Serial interface

• Redundant and hybrid power combining systems

• Integrated 1:1 or 1:2 switch control and drive

• Integral linearizer

• Integral block upconverter (BUC)

• External receive band reject filter (minimum 115 dB rejection from 7.25 to 7.75 GHz)

• Low Passive Intermodulation (Low PIM) option

• Reduced radiated emissions configuration

• TWT LifeExtender™ and LifePredictor™ for extended tube life
