CPI T07DO-L1

CPI 750 W DBS-Band Outdoor TWTA — Model T07DO-L1

High-Power, Rugged Outdoor Amplifier for Satellite Uplink Applications

The CPI T07DO-L1 provides up to 750 watts of output power in a compact, weatherproof design, ideal for both fixed and transportable earth stations operating in the 17.3 to 18.4 GHz DBS-band.
Built for digital satellite uplinks, it combines high performance, reliability, and ease of integration.

Key Features:

• 750 W of output power in a compact outdoor package

• High-efficiency helix TWT with dual-depressed collector reduces operating costs

• Weatherproof and rugged construction for harsh environments

• CAN-Bus architecture improves system reliability and noise immunity

• Microprocessor control with Ethernet and SNMP (v1, v2, v3) interface

• Digital metering and PIN diode attenuation for precise control

• Optional integrated linearizer for enhanced intermodulation performance

• Optional LifeExtender™ extends tube life by up to 50%

Certifications:

• ISO 9001:2015 Certified

• EN-60215 Safety Standard

• EMC Directive 2014/30/EU Compliant

• EN-61000-3-2 Harmonic Standard

• CE Marked for global deployments

Available Options:

• Remote control panel (1 RU)

• Serial interface

• Redundant and hybrid power combining configurations

• Integrated 1:1 switch control and drive

• Integral linearizer

• Integral block upconverter (BUC) [see CPI TD-187 for details]

• TWT LifeExtender™ and LifePredictor™

• Inlet air filter

• Air cooling system

• Uplink Power Control

Global Support:
Supported by CPI’s global network of over 20 regional factory service centers and 24/7 customer service, backed by more than 40 years of satellite communications expertise.

Applications:

• Fixed Earth Stations

• Mobile and Transportable Uplink Systems

• Broadcast and SNG (Satellite News Gathering)

• Emergency and Disaster Recovery Communications

Deliver high-power, reliable uplinks with CPI’s proven DBS-band technology.
